Material:
Housing: Carbon steel, 1.5 mm Door and console lid: Carbon steel, 2.0 mm, all-round foamed-in PU seal Mounting plate: Carbon steel, 2.5 mm
Base Material:
Carbon steel
Surface Finish:
Housing, cover and door: Dipcoat-primed, powder-coated on the outside, textured paint Mounting panel: Zinc-plated
Color:
RAL 7035
Supply Includes:
Housing, solid back and sides Door or double door at front, with 3-point locking system Mounting panel Cover with cam locks, hinged at rear, 2 stays with automatic locking. Unlocking automatically on the left, manually on the right. Gland plate Lock:
Mounting Plate Dims:
720 mm x 900 mm ( 28.3 ? x 35.4 ? )
Number of Doors:
1
Width (mm):
800mm
Height (mm):
970mm
Depth (mm):
400mm
Width (in):
31.5in
Height (in):
38.2in
Depth (in):
15.7in
IP Rating:
IP 55
IK Code:
IK10
NEMA Rating:
NEMA 1 | NEMA 12
Customs Tariff No:
94032080
Packaging Unit:
1 pc(s).
Net Weight (kg):
58.000
Net Weight (lb):
127.868
Gross Weight (kg):
60.000
Gross Weight (lb):
132.277
EAN:
4028177983601
ETIM 9:
EC000784
ETIM 8:
EC000784
ECLASS 8.0:
27180504
