Material:
Enclosure frame: Carbon steel, 1.5 mm Roof: Carbon steel, 1.5 mm Door: Carbon steel, 2.0 mm Rear wall: carbon steel, 1.5 mm Base plates: Carbon steel, 1.5 mm Mounting panel: Carbon steel, 3.0 mm
Base Material:
Carbon steel
Surface Finish:
Enclosure frame: Dipcoat-primed Door, roof and rear panel: Dipcoat-primed, powder-coated on the outside, textured paint Mounting plate and base plates: Zinc-plated
Color:
RAL 7035
Supply Includes:
Enclosure frame Door(s) Right-hand door catch on single-door enclosures may be swapped to the left Roof plate Rear panel 4 eyebolts Lock: 3 mm double-bit Base Plates Mounting panel 2 TS punched rails, 18 x 38 mm 2 support strips fitted in the enclosu
Mounting Plate Dims:
1,099 mm x 2,096 mm ( 43.3 ? x 82.5 ? )
Number of Doors:
2
Depth (mm):
600mm
Width (in):
47.2in
Height (in):
86.6in
Depth (in):
23.6in
IP Rating:
IP 55
IK Code:
IK09
NEMA Rating:
NEMA 1 | NEMA 12
UL Type Rating:
Type 1 | Type 12
Customs Tariff No:
94032080
Packaging Unit:
1 pc(s).
Net Weight (kg):
197.600
Net Weight (lb):
435.633
Gross Weight (kg):
208.000
Gross Weight (lb):
458.561
EAN:
4028177250901
ETIM 9:
EC000261
ECLASS 8.0:
27180101
