Material:
Housing: Stainless steel Door: Stainless steel, all-round foamed-in PU seal Mounting plate: Carbon steel Stainless steel 1.4301 (AISI 304)
Base Material:
Stainless steel 1.4301 (AISI 304)
Surface Finish:
Housing and door: Brushed, grain 400, peak-to-valley height < 0.8 µm Mounting panel: Zinc-plated
Supply Includes:
Housing with door(s), swing angle 130° Mounting panel Lock: 3 mm double-bit
Mat Thick - Door:
1.5 mm (0.06 in)
Mat Thick - Enclosure:
1.25 mm (0.05 in)
Mat Thick - Mtg Plate:
2.5 mm (0.1 in)
Mounting Plate Dims:
550 mm x 575 mm ( 21.7 ? x 22.6 ? )
Number of Doors:
1
Lock Details:
Lock version: Cam No. of locks: 2 Lock Insert: 3 mm double-bit Material lock: Die-cast zinc
Width (mm):
600mm
Height (mm):
600mm
Depth (mm):
210mm
Width (in):
23.6in
Height (in):
23.6in
Depth (in):
8.27in
IP Rating:
IP 66
IK Code:
IK10
NEMA Rating:
NEMA 1 | NEMA 3R | NEMA 4 | NEMA 4X | NEMA 12
UL Type Rating:
Type 1 | Type 3R | Type 4 | Type 4X | Type 12
Customs Tariff No:
94032080
Packaging Unit:
1 pc(s).
Net Weight (kg):
19.900
Net Weight (lb):
43.872
Gross Weight (kg):
20.140
Gross Weight (lb):
44.401
EAN:
4028177814998
ETIM 9:
EC000261
ETIM 8:
EC000261
ECLASS 8.0:
27180101
