Material:
Housing: Stainless steel Door: Stainless steel, all-round foamed-in PU seal Mounting plate: Carbon steel Stainless steel 1.4301 (AISI 304)
Base Material:
Stainless steel 1.4301 (AISI 304)
Surface Finish:
Housing and door: Brushed, grain 400, peak-to-valley height < 0.8 µm Mounting panel: Zinc-plated
Supply Includes:
Housing with door(s), swing angle 130° Mounting panel Lock: 3 mm double-bit
Mat Thick - Door:
2 mm (0.08 in)
Mat Thick - Enclosure:
1.5 mm (0.06 in)
Mat Thick - Mtg Plate:
2.5 mm (0.1 in)
Mounting Plate Dims:
945 mm x 1,175 mm ( 37.2 ? x 46.3 ? )
Number of Doors:
2
Lock Details:
Lock version: 3-point locking system No. of locks: 1 Lock Insert: 3 mm double-bit Material lock: Stainless steel 1.4404 (AISI 316L)
Depth (mm):
300mm
Width (in):
39.4in
Height (in):
47.2in
Depth (in):
11.8in
IP Rating:
IP 55
IK Code:
IK10
NEMA Rating:
NEMA 1 | NEMA 12
UL Type Rating:
Type 1 | Type 12
Customs Tariff No:
94032080
Packaging Unit:
1 pc(s).
Net Weight (kg):
71.400
Net Weight (lb):
157.410
Gross Weight (kg):
78.000
Gross Weight (lb):
171.960
EAN:
4028177815056
ETIM 9:
EC000261
ETIM 8:
EC000261
ECLASS 8.0:
27180101
